HT29 Split Bollard Grip

Slide1
Slide2
Slide3
Slide4
Slide5
previous arrow
next arrow
Slide1
Slide2
Slide3
Slide4
Slide5
previous arrow
next arrow
When using the HT29 Split Bollard Grip, the specimen is wrapped around the split bollard and retained between two serrated jaw faces. The large circumference of the bollard reduces the concentration of stress within the specimen at the point of clamping, thereby preventing breaks occurring between the jaw faces.



The single bollard self-tightening grip is used on benchtop materials testing machines.



Specifications

  • Item# : 99-029-0000
  • Maximum capacity: 5kN/1,000lbf
  • Minimum loadcell: 100N/20lbf
  • Maximum specimen diameter: 10mm/0.39in
  • Length each: 130mm/5.1in
  • Weight each: 1kg/2.2lb
  • Temperature limits: -30-70°C

    •

    Applications

  • Light ropes
  • Cords
  • Cables
  • Flexible tubing
  • Flexible tape
  • Fishing line
    • Download Brochure
    • Request a Quote
